Ellies Single Phase Hoymiles Consumption Meter - RS485
R789.00
SKU
FBIAM1RS
Description
The Ellies Single Phase Hoymiles Consumption Meter - RS485 communicates RS485 from the DB board to Data Transfer Unit and is mainly used for measuring and displaying vital current, power, frequency, power factors and other parameters in an electrical circuit. Widely used for energy monitoring and assessment in industrial applications, this product features a modular design and a small and compact build for easy installation.
Features
- Four Quadrant Reactive Power Meter
- Single Phase
- Measures Consumption for Anti-reflux Control
- RS485 Communication with Hoymiles DTU/s
- DIN Rail Mountable
- Displays: Current, Power, Frequency, Power Factor & Other Parameters
- Modular Design
- Small & Compact for Easy Installation
Specifications
| Dimensions | 36mm x 85mm x 66mm |
| Display Mode | LCD |
| Frequency | 50Hz/60Hz |
| Reference Voltage | 230V |
| Range of Measurement | 0～999999.99 kWh (Only show 6 bits, decimal shift automatically) |
| Current Rating | 5(60)A |
| Constant | 800imp/kWh |
| Type | Direct Access Meter |
| Accuracy Grade | Active Power 1 |
| Communication Protocol | DL/T 645-2007 (default) Modbus-RTU |
| Rated Temperature | -25 - +55 Celsius |
| Limit Temperature | -40 - +70 Celsius |
| Relative Humidity | ≤75% |
| Atmosphere | 86kPa ~ 106kPa |
| Free Shipping | No |
|---|
