Meteo Control Schneider E-meter - IEM3255
R6,549.00
SKU
4200200016
- Multi tariff measurement
- MID approval
- Pulse output
- Display (current, voltage and power measurements)
Description
The Meteo Control Schneider E-meter offers all the essential measurement functions, for example, current, voltage and energy, that are needed for monitoring three-phase electrical installations.
Features
- Measuring voltage, current, active and reactive power, as well as active and reactive energy
- Can be used as a bidirectional meter for measuring grid feed-in and sourcing
- Multi tariff measurement
- MID approval
- Pulse output
- Display (current, voltage and power measurements)
- Communication via Modbus RTU
Specifications
| Conductor systems | 1P + N (100 - 277 VAC) |
| 3P (173 - 480 VAC) | |
| 3P + N (173 - 480 VAC) | |
| Current measurement range | 0.02 - 6 A |
| Transformer inputs: 1 A or 5 A | |
| Precision class | Active power: Class C as per EN 50470-3 |
| Active power: Class 0.5S as per IEC 61557-12 | |
| Active power: Class 0.5S as per IEC 62053-22 | |
| Rated current in operation | 1 A / 5 A |
| Nominal voltage | 173 V - 480 V |
| 100 V - 277 V | |
| Grid frequency | 50 Hz / 60 Hz |
| Maximum / startup / minimum current | for x / 1 A current input: for x / 5 A current input: |
| (active power) | Imax = 1.2 A, Ist = 0.002 A, Imin = 0.01 A Imax = 6 A, Ist = 0.005 A, Imin = 0.05 A |
| Power consumption | < 0.036 VA at 6 A |
| Sampling rate | 32 samplings / cycle |
| Tariff input | 4 tariffs |
| Communication interface | RS485, Modbus RTU 9,600, 19,200 and 38,400 baud odd/even or no parity |
| Inputs | 1 digital input 0 - 5 VDC / 11 - 40 VDC (rated voltage 24 VDC) |
| Outputs | 1 digital output (static) 5 - 40 VDC < 50 mA |
| Display type | LCD display |
| Active power display range | 99,999,999 [kWh] or [MWh] |
| Free Shipping | No |
|---|
