DJI Matrice 30 BS30 Intelligent Battery Station
R0.00
SKU
DJI-TB30 BATT STATION
Charges two aircraft batteries, one RC battery (W837), and one RC Plus at the same time
Aircraft batteries are charged in vertical pairs
Cannot transport batteries inside the case
Manufacturer's Website
Description
The DJI Matrice 30 BS30 Intelligent Battery Station is a smart, portable solution with multiple charging modes to meet your mission needs. Capable of charging four pairs of TB30 Intelligent Flight Batteries and one pair of RC Plus batteries, pairs are charged one at a time, with one pair taking just 30 minutes to charge from 20-90%.
Features
- Charges two aircraft batteries, one RC battery (W837), and one RC Plus at the same time
- Aircraft batteries are charged in vertical pairs
- Cannot transport batteries inside the case
Specifications
| Dimensions | 353x267x148 mm |
| Net Weight | 3.95 kg |
| Compatible Battery Type | TB30 Intelligent Flight Battery, WB37 Intelligent Battery |
| Input | 100-240 VAC, 50/60 Hz |
| Output | TB30 Battery Port: 26.1 V, 8.9 A (supported up to two outputs simultaneously), WB37 Intelligent Battery: 8.7 V, 6 A |
| Output Power | 525 W |
| Usb-C Port | Max. output power of 65 W |
| Usb-A Port | Max. output power of 10 W (5 V, 2 A) |
| Power Consumption (When Not Charging Battery) | < 8 W |
| Output Power (When Warming Up Battery) | Approx. 30 W |
| Operating Temperature | -20 to 40 C (-4 to 104 F) |
| Ingress Protection Rating3 | IP55 (with the cover closed properly) |
| Charging Time6 | Approx. 30 min (charging two TB30 batteries from 20% to 90%), Approx. 50 min (charging two TB30 batteries from 0% to 100%) |
| Protection Features | Anti-Backflow Protection, Short Circuit Protection, Overvoltage Protection, Overcurrent Protection, Temperature Protection |
| Free Shipping | No |
|---|
