Dsppa MP9312U Ultra-Thin Digital Mixer Amplifier - 120W
R6,499.00
SKU
DSPPMP9312U
Bluetooth, USB and line modes
100 VRS prior line input
EMC input
Shipping restrictions apply.
Description
Introducing the Dsppa Mp9312U Ultra-Thin Digital Mixer Amplifier - 120W. A powerful and versatile audio solution designed to elevate your audio experience. With a robust output of 120W, this amplifier offers three working modes: Bluetooth, USB, and Line, providing flexibility and convenience for various audio sources.
The MP9312U features wireless Bluetooth playback, allowing you to effortlessly connect your devices for seamless audio streaming. The included remote control enhances user convenience, making it easy to manage your audio settings from a distance.
Equipped with essential indicators, including Signal Level Indicator (SIG), Clip Indicator (CLIP), and Protection Indicator (PRO), this amplifier ensures precise monitoring of audio signals for optimal performance.
Featuring multiple input options, such as 2 MIC inputs with phantom input and priority input, and 2 line inputs, the MP9312U accommodates diverse audio input requirements. Additionally, it includes 1 line 100V output and 1 line auxiliary output, offering versatile connectivity options for various setups.
The priority setting establishes a seamless audio experience, with a priority hierarchy of 100V input priority > Mic1 > others. The amplifier provides reliable protection with short-circuit, overload, and high-temperature protection, supported by a temperature-controlled fan to maintain an optimal operating environment.
For personalized audio control, the MP9312U offers individual volume control for Mic 1-2, Line 1-2, bass/treble adjustments, and master volume control. The tone controls include a Bass adjustment of 10dB (100Hz) and Treble adjustment of 10dB (10kHz), allowing you to tailor the audio output to your preferences.
Compact and ultra-thin, with machine dimensions of 200x190x44mm and a net weight of 1.5kg, the DSPPA MP9312U Ultra-Thin Digital Mixer Amplifier combines power, versatility, and sleek design, making it an excellent choice for applications where high-quality audio and space efficiency are paramount.
Please Note: Please use a constant-voltage speaker within the power range.
Features
- Bluetooth, USB and line modes
- Wireless Bluetooth playing
- With signal level indicator (sig)
- Clip indicator (clip)
- Protection indicator (pro)
- 100 VRS prior line input
- EMC input
- 2 mic inputs, with phantom input and priority input, 2 lines input
- With 1 line 100v outputs and 1 line auxiliary outputs
- Priority: 100v input priority> mic1>others
- With short-circuit, overload and high temp protection, temperature-controlled fan
- Individual volume control for mic 1-2, line 1-2, bass/treble and master volume control
Specifications
| Model | MP9306U |
| Rated Output Power | 120W |
| Rated Output Voltage | 100V |
| Sensitivity | |
| Mic1 In | 0.005(+-1mV) |
| Mic2 In | 0.006(+-1mV) |
| Line1 In, Line2 In, Priority In | 0.3(+-20mV)VRMS |
| Priority In-100V | 100 VRMS |
| Snr | |
| Mic1, Mic2, Line1 In | Approximately 74db(MAX.) |
| Line2 In, Input Priority | Approximately 80dB(MAX.) |
| Frequency Range | 80Hz-15kHz (+-3dB) |
| THD | Approximately 0.5% (1K under normal working condition) |
| Working Voltage | AC180-250V/50-60Hz |
| Tone | |
| Bass | +- 10dB (100Hz) |
| Treble | +- 10dB (10kHz) |
| Rated Power Consumption | 180W |
| Package Dimensions (LxWxH) | 310x275x120mm |
| Machine Dimensions (LxWxH) | 200x190x44mm |
| Net Weight | 1.5kg |
| Gross Weight | 2kg |
| Free Shipping | No |
|---|
