Hikmicro NEOS NH25L Thermal Imaging Riflescope
320x240 Sensor Resolution
1200m Detection Range
3.5x - 24.5x Magnification
Less than 18 mK (at 25C, F 1.0)


Description
Introducing the Hikmicro NEOS NH25L Thermal Imaging Riflescope. A powerful and lightweight thermal optic engineered for hunters and professional shooters who demand precision, reliability, and advanced targeting capabilities. Built around a high-performance 320 x 240 VOx uncooled thermal sensor with a thermal sensitivity of less than 18mK NETD, the NH25L captures crisp thermal images with outstanding detail in complete darkness, fog, rain, and other challenging conditions. Its fast 25mm F1.0 objective lens and detection range of up to 1,200 metres provide excellent target acquisition at medium to long distances, while the variable 3.5x to 24.5x magnification offers the flexibility to scan wide areas or zoom in for precise identification.
The riflescope delivers an immersive viewing experience through its large 0.49-inch AMOLED display with a sharp 1920 x 1080 resolution. Users can optimise the display using adjustable brightness, contrast, and tone settings, while six selectable colour palettes-including Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, and Green Monochrome-allow for enhanced visibility in a variety of environments. With a 55mm eye relief, 8mm exit pupil, manual focus ring, and a wide field of view, the NEOS NH25L is designed for comfortable viewing and rapid target acquisition during extended hunting sessions. Advanced imaging technologies further enhance performance with HIKMICRO's Shutterless Image System (HSIS), which eliminates image freezing during calibration for uninterrupted observation. Image Pro 3.0, Zoom Pro, and Sync Pro algorithms work together to improve image clarity, digital zoom performance, and reduce display latency for smoother viewing. The integrated Class 1 laser rangefinder measures distances up to 1,000 metres with an accuracy of 1 metre, while the built-in ballistic calculation function provides precise holdover information to improve long-range shooting accuracy. Additional features including picture-in-picture mode, recoil-activated recording, onboard video and audio recording, snapshot capture, freeze zeroing, distance measurement, five zeroing profiles, and 64GB of built-in eMMC storage provide a comprehensive shooting solution both in the field and at the range.
Built to withstand demanding outdoor environments, the Hikmicro NEOS NH25L features a rugged IP67-rated construction and a standard 30mm mounting tube for easy installation on compatible rifles. Weighing only 550 grams, the compact and ergonomic design ensures comfortable handling without adding unnecessary weight to your firearm. A dual-battery system combines an internal rechargeable battery with a replaceable 18650 lithium-ion battery, delivering up to nine hours of continuous operation while supporting USB Type-C charging and Quick Charge 3.0 compatibility. With its rapid one-second start-up time, support for the Sight App's quick zeroing function, and advanced thermal imaging technology, the Hikmicro NEOS NH25L offers a complete, high-performance solution for accurate target detection and confident shooting in any lighting condition.
Features
- Up to 6 Colour Palettes
- 0.49-inch AMOLED, 19201080
- Up to 9 hours Max Battery Life
- Built-in EMMC (64 GB)
- HIKMICRO Shutterless Image System (HSIS) & Zoom Pro
- 550g lightweight, with a compact and ergonomic design
- 1000m Laser Rangefinder with Ballistic Calculation
- 1-second Quick Start-up
- Quick Zeroing on Sight APP
Specifications
| Brand | Hikmicro |
| Thermal Module | |
| Image Sensor | VOx Uncooled Focal Plane Arrays |
| Max. Resolution | 320 x 240 |
| Frame Rate | 50 Hz |
| Pixel Interval | 12um |
| Response Waveband | 8um to 14um |
| Netd | Less than 18 mK (at 25C, F 1.0) |
| Lens (Focal Length) | 25mm, F1.0 |
| Detection Range | 1200m |
| Focus Mode | Focus Ring |
| Field Of View(H X V), Degrees / M At 100M | 7.0 x 5.3/ 12.2 m x 9.3 m |
| Min. Focusing Distance | 3m |
| Magnification | 3.5x - 24.5x |
| Image Display | |
| Display | 0.49-inch AMOLED, 19201080 |
| Contrast Adjustment | Yes |
| Brightness Adjustment | Yes |
| Palettes | Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, Green Monochrome |
| Exit Pupil | 8mm |
| Eye Relief | 55mm |
| Diopter (Range) | -4D to 4D |
| Tone Adjustment | Cold, Warm |
| Zoom Pro | Yes |
| Hsis (Hikmicro Shutterless Image System) | Yes |
| Image Pro 3.0 | Yes |
| Sync Pro | Yes |
| General | |
| Protection Level | IP67 |
| Weight | 550g |
| Dimension | 345.6mmx86.1mmx75.8mm |
| Mounting | Standard 30mm |
| Working Temperature | -30 C to 55 C (-22 F to 131F) |
| Center Height | 32mm |
| System | |
| Record Video | On-board Video Recording |
| Capture Snapshot | Yes |
| Hotspot | Yes |
| Standby Mode | Yes |
| Storage | Built-in EMMC (64 GB) |
| Pip | Yes |
| Distance Measurement | Yes |
| Audio Recording | Yes |
| Recoil-Activation Recording | Yes |
| Freeze Zeroing | Yes |
| Max. Recoil | 1000g/0.4ms |
| Local Album | Yes |
| Zeroing Profiles | 5 |
| Ballistic Calculation | Yes |
| Click Value | 1 click 1cm at 100m |
| Power Supply | |
| Battery Type | One Rechargeable Lithium Battery (Internal), One Replaceable and Rechargeable 18650 Battery (External) |
| Battery Operating Time | 9 hours continuous running (at 25C, Zoom Pro, LRF on) |
| Type-C Power Supply | 5 V DC/2 A, USB Type-C interface |
| Supports QC3.0 | |
| Only the built-in battery will be charged via the type-C cable. Use the battery charger to charge the external battery. | |
| Laser Rangefinder | |
| Safety Class For Laser | Class 1 |
| Wavelength | 905 nm |
| Max. Measuring Range | 1000 m |
| Measurement Accuracy | -/+ 1 m |
| Min. Measuring Range | 10 m |
Package Contents
- 1x hikmicro neos nh25l thermal image scope
- 1x quick start guide
- 1x type-c cable
- 1x lint-free cloth
- 2x battery
- 1x battery charger
